Spiral Bending Machine Manufacturer in Ahmedabad
We design and manufacture precision spiral bending machines in Ahmedabad for forming coils, helixes, and rings in rebar, pipe, flat bar, and wire. Built on a rigid chassis with hardened tooling and controlled feed systems, our machines deliver repeatable diameters, smooth curvature, and high productivity for fabrication shops, infrastructure, and architectural metalwork.
How a Spiral Bending Machine Works
Material is driven through powered rollers or a central mandrel while guide rollers control curvature. By adjusting roller offsets, feed speed, and diameter presets, the machine forms consistent spirals or rings. A reinforced frame and precision bearings minimize deflection, ensuring accurate pitch, diameter, and surface finish across long production runs.
Types of Spiral Bending Machines We Offer
- Three-roll powered spiral benders for pipe, tube, and flat bar sections.
- Rebar spiral ring bending machines for RCC cages and helical stirrups.
- Wire/strip spiral formers for light-gauge coils and springs.
- Heavy-duty mandrel-based helix benders for large diameters.
- CNC controlled variants with programmable diameter and pitch presets.
Key Features and Specifications
- Hardened drive and guide rollers with quick alignment reference marks.
- Servo/AC drive options for smooth torque and fine feed control.
- Digital diameter gauge and pitch setting for repeatability.
- Rigid welded frame and anti-vibration mounts to protect accuracy.
- Safety interlocks, E-stop, and protective guards for operator safety.
Applications
- Rebar spirals for columns, piles, and circular RCC structures.
- Architectural handrails, helical stair stringers, and decorative rings.
- Coils for HVAC duct supports, cable trays, and industrial fixtures.
- Process industry rings, flanges, and custom helical components.
Benefits of Our Spiral Bending Machines
- Consistent diameters and pitch with minimal rework.
- High throughput with stable feed and torque control.
- Versatile tooling for rebar, tube, flat bar, and wire.
- Low maintenance design suited to Indian fabrication conditions.
Selection Guide for Ahmedabad Buyers
Match the machine to section type (rebar, pipe, flat bar, wire), max diameter, and target pitch. Evaluate motor power, roller hardness, minimum achievable radius, and CNC/preset capability. For continuous production, prefer oversize bearings, accessible lubrication points, and calibrated reference scales for quick changeovers.
Maintenance and Safety Tips
- Inspect rollers for wear and surface scoring; recondition or replace as required.
- Verify diameter and pitch presets using a gauge before each batch.
- Lubricate bearings and screw assemblies per schedule to prevent heat build-up.
- Keep guards in place; test emergency stop and interlocks at shift start.
- Clean metal chips and dust to protect drives, sensors, and control panels.
FAQs – Spiral Bending Machine
Contact Details
Talk to our specialists today for tailored solutions and fast assistance.
